LiuGong Excavators
LiuGong excavators (diggers) are competitively priced with no compromise to their capabilities.
LiuGong products are being used by a wide range of customers across Australia. LiuGong wheel loaders, rollers, graders and excavators are successfully working and servicing local government, civil contractors, quarries and agricultural operations.
Electric Machines
LiuGong has released their new electric excavator: revolutionising efficiency and sustainability.
9017F ZTS
Engine: Kubota D902
Net Power: 15.8 hp (11.8 kW / 16 ps) @ 2,300 rpm
Maximum Dig Depth: 2,255 mm (7'5")
Standard Bucket Capacity: 0.045 m³ (0.06 yd3)
Operating Weight (steel track): 1,850 kg (4,078 lbs)
Operating Weight (rubber track): 1,750 kg (3,858 lbs)
9018F
Bucket capacity: 0.056 m3
Operating weight: 1,800 kg
Rated power: 17.9 hp (13.4 kW) @ 2200 rpm
Net Power: 18.2 hp @ 2,200 rpm
Maximum digging depth: 2,290 mm
9027F ZTS
Bucket capacity: 0.08 m3
Operating weight: 2,680 kg
Net Power: 20.4 hp (20.7 ps) @ 2,2000 rpm
Maximum digging depth: 2,857 mm
9035E ZTS
Engine: Yanmar 3TNV88-BPLY
Net Power: 29.8 hp (22.2 kW / 30.2 ps) @ 2,400 rpm
Standard Bucket Capacity: 0.11 m3
Operating Weight: 3,980 / 3,860 kg
9035F ZTS
Engine: Yanmar
Net Power: 23.2 hp
Operating Weight: 3,800 kg
9057F ZTS
Engine: Yanmar 4TNV86CT-PLY
Rated Power: 48 hp @ 2,200 rpm
Standard Bucket Capacity: 0.16 m3
Operating Weight: 5,570 kg
909E CR
Engine: Yanmar Tier 5
Rated Power: 62 hp (46.2 kW / 63 ps) @ 2,200 rpm
Net Power: 59 hp (44 kW / 60 ps) @ 2,200 rpm
Maximum Dig Depth: 4,093 mm
Standard Bucket Capacity: 0.28 m³
Operating weight: 8,700 kg
915E
Powered by Cummins
Rated Power: 115 hp (86 kW) @ 2,200 rpm
Net Power: 108 hp (80.2 kW) @ 2,200 rpm
Bucket capacity: 0.6 m3
Operating weight: 14,950 kg
Maximum digging depth: 5,470 mm
915F CR
Emission Regulation: Tier 4f / Stage V
Engine: Cummins F3.8
Rated Power: 120.6 hp (90 kW)
Net Power: 113.3 hp (84.5 kW) @ 2,200 rpm
Standard bucket capacity: 0.55 m3
Peak Torque: 500 N·m @ 1,500 rpm
Number of Cylinders: 4
Operating weight: 16,600 kg
Maximum digging depth: 5,515 mm
922E
Powered by Cummins
Rated Power: 166 hp (124 kW) @ 2,050 rpm
NetPower: 157 hp (117 kW) @ 2,050 rpm
Bucket capacity: 1.0 m3
Operating weight: 22,000 kg
Maximum digging depth: 6,562 mm
922F
Powered by Cummins
Rated Power: 166 hp
Net Power: 147 hp @ 2,200 rpm
Bucket capacity: 1.1 m3
Operating weight: 22,800 kg
924F
Powered by Cummins
Net Power: 167 hp @ 2,050 rpm
Operating weight: 24,900 kg
Reach: 10 - 11 m
925E
Powered by Cummins
Net Power: 177 hp @ 2,050 rpm
Bucket capacity: 1.4 m3
Operating weight: 26,400 kg
Maximum digging depth: 6,925 mm
930E
Powered by Cummins
Net Power: 216 hp @ 1,900 rpm
Bucket capacity: 1.6 m3
Operating weight: 32,900 kg
Maximum digging depth: 7,300 mm
933F
Powered by Cummins
Rated Power: 226 hp
Net Power: 219 hp @ 2,000 rpm
Bucket capacity: 0.5 m3
Operating weight: 34,300 kg
936F
Powered by Cummins
Net Power: 298 hp @ 2,100 rpm
Bucket capacity: 1.8 m3
Operating weight: 38,800 kg
939F
Powered by CN III QSL
Rated Power: 286 hp
Bucket capacity: 2.0 m3
Operating weight: 39,000 kg
950E
Powered by Cummins
Rated Power: 376 hp (280 kW) @ 2,000 rpm
Net Power: 354 hp (260 kW) @ 2,000 rpm
Bucket capacity: 3.2 m3
Operating weight: 46,500-48,300 kg
Maximum digging depth: 6,521 mm
975F
Powered by Cummins
Net Power: 755 hp (563 kW) @ 2,100 rpm
Bucket capacity: 5.0 m3
Operating weight: 78,500 kg
990F
Powered by Perkins
Rated Power: 582 hp @ 1,800 rpm
Operating weight: 95,000 kg
9125F
Powered by Cummins
Net Power: 760 hp @ 1,800 rpm
Operating weight: 122,000 kg
McIntosh & Son is an authorised dealer for LiuGong. LiuGong wheel loaders are available in Western Australia at these branches: Albany, Cunderdin, Esperance, Geraldton, Katanning, Kulin, Merredin, Moora, Narrogin, Perth (Redcliffe), Wongan Hills and Dalby (QLD). McIntosh & Son can arrange delivery of pre-owned (used) machines anywhere in Australia.
McIntosh & Son offers a comprehensive, friendly and professional one-stop shop service. We are committed to our customers and aim to provide easy and quick access to sales of new and used machines, quality service and parts.
To order or find out more information, contact a McIntosh & Son branch today.
